16711 Outer Silk Series

The 16711 outer wire series products are mainly used to achieve connections between different pipelines and equipment, and are key components in various fluid transmission systems such as hydraulic systems, pneumatic systems, water supply and drainage systems, etc. With its external thread structure, it can be tightly connected to pipes or equipment interfaces with internal threads, protecting the stable and safe transmission of fluids.

Material characteristics

Mostly made of materials such as stainless steel, high-quality carbon steel, or copper alloy. The 16711 outer wire joint made of stainless steel material has effective corrosion resistance and can work stably in high corrosion environments such as coastal areas and chemical production; After heat treatment and surface treatment, carbon steel material can balance high strength and certain corrosiveness, making it suitable for high-pressure and heavy-duty working conditions; Copper alloy material has good thermal conductivity, electrical conductivity, and corrosiveness, and is commonly used in special occasions where the purity and working temperature of the medium are required.

structural design

External thread section: The external thread strictly follows relevant reputation or national standards (such as ISO standards, ASME standards, etc.), with fine tooth profile and uniform pitch, protecting the tightness and interchangeability when matched with internal thread fittings. The threaded surface is specially treated, such as galvanizing, nickel plating, etc., to further enhance rust prevention and performance.

Connecting the main body: The pipe body is usually designed with a determined length and wall thickness to withstand fluid pressure and external forces. Some of the joint surfaces have patterns or rolling patterns, which can increase friction and prevent loosening when connected to hoses and other materials.

Installation and operation section: The joint is equipped with a structure that facilitates installation and operation, commonly with hexagonal or octagonal nut parts, which facilitate the use of tools such as wrenches for quick and meticulous installation and disassembly, improving construction efficiency.

performance parameters

Work pressure: Depending on the material and specifications, the range of work pressure varies greatly. Generally, low-pressure models can withstand pressures of 1-5MPa, while medium and high-pressure models can withstand pressures of 10-50MPa or even higher, meeting the requirements of different working conditions.

Applicable temperature range: Conventional products are suitable for temperatures around -20 ℃ -100 ℃, while special materials or specially designed products can operate in a temperature range of -40 ℃ -150 ℃ or even wider.

Pipe diameter adaptation: There are multiple specifications to choose from, with pipe diameters ranging from a few millimeters (such as for fluid transmission in delicate instruments) to tens of millimeters (such as industrial pipeline systems), suitable for pipes of different thicknesses.

Application scenarios

Industrial manufacturing: In the hydraulic systems of machine tools, injection molding machines, and other equipment, hydraulic components are connected to achieve the circulation of hydraulic oil and power transmission, protecting the normal operation of equipment.

Petrochemical industry: used for pipeline connection in petroleum and chemical production processes, transporting various chemical raw materials, oil products, etc., requiring joints to have good corrosion and high pressure resistance performance.

Building facilities: Connect water pipes in the building's water supply and drainage, fire sprinkler, and other systems to ensure smooth water flow and protect the building's water safety.

Transportation: Used in the braking system and fuel supply system of automobiles, as well as the hydraulic and fuel pipeline systems of ships and aircraft, with high requirements for product quality and safety.
